| Engine | |
|---|---|
| Model | KX65 |
| Engine Type | Liquid-cooled, 2-stroke Single |
| Displacement | 64.7 cm³ |
| Bore X Stroke | 44.5 x 41.6 mm |
| Compression Ratio | 8.4:1 |
| Valve System | 4 petal piston reed valve |
| Fuel System | Carburettor: Mikuni VM24SS |
| Ignition | Digital CDI |
| Starting | Primary Kick |
| Transmission | 6-speed, return |
| Clutch | Wet multi-disc, manual |
| Frame | |
|---|---|
| Type | High-tensile steel semi-double cradle with detachable left-side rear section |
| Wheel Travel Front | 210 mm |
| Wheel Travel Back | 240 mm |
| Tyre | |
|---|---|
| Front | 60/100-14 (30M) |
| Rear | 80/100-12 (41M) |
| Suspension | |
|---|---|
| Front | 33 mm telescopic fork with 4-way rebound damping |
| Rear | Bottom-Link Uni-Trak with gas-charged shock, adjustable preload and 4-way rebound damping |
| Brakes | |
|---|---|
| Front | Single 180 mm disc with single-piston caliper |
| Rear | Single 180 mm disc with single-piston caliper |
| Dimensions | |
|---|---|
| L x W x H | 1,590 x 760 x 955 mm |
| Wheelbase | 1,120 mm |
| Ground Clearance | 305 mm |
| Seat Height | 760 mm |
| Curb Mass | 60.0 kg (includes full fuel tank, all fluids at optimum levels) |
| Fuel Capacity | 3.8 litres |
| Performance | |
|---|---|
| Colour/s | Lime Green |
